Standard Bar Sinks
- 18 gauge, Type 304 stainless steel construction for lasting durability
- Coved corners for safety and easy cleaning
- Die-stamped drain boards and sink bottoms for positive drainage
- Wall clips are provided for neat and easy installation
- All sinks come with 4" center pre-cut holes for standard wall mount faucets (faucet not included)
- Corner drain sink with a 1½" diameter drain hole and come with 3.5” drain basket
- Sink wells are 10" deep
- All TIG welded
- Welded areas are blended to match adjacent surface and blended to a satin finish
- Gussets are welded to a die embossed reinforced plate
- 1 5/8" diameter galvanized legs with 1” adjustable plastic bullet feet
NSF Certified
Product Specifications
| Product # | SIB-1N | SIB-1L | SIB-1R | SIB-1B | SIB-2N | SIB-2L | SIB-2R | SIB-2B | SIB-3N | SIB-3L | SIB-3R | SIB-3B-60 | SIB-3B-72 | SIB-4B |
| Bowls | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 3 | 4 |
| Shipping Dimensions WxDxH | 24"x22"x17" | 26"x22"x17" | 26"x22"x17" | 38"x22"x17" | 28"x22"x17" | 38"x22"x17" | 38"x22"x17" | 50"x22"x17" | 40"x22"x17" | 50"x22"x17" | 50"x22"x17" | 62"x22"x17" | 74"x22"x17" | 74"x22"x17" |
| Weight (lbs) | 56 | 67 | 67 | 76 | 85 | 96 | 96 | 106 | 115 | 125 | 125 | 135 | 150 | 150 |
| Overall Width(W) | 14 1/2" | 24" | 24" | 36" | 26 1/2" | 36" | 36" | 48" | 39 1/2" | 48" | 48" | 60" | 72" | 72" |
| Drainboards | 0 | 1 | 1 | 2 | 0 | 1 | 1 | 2 | 0 | 1 | 1 | 2 | 2 | 2 |
| Drainboard (A) | N/A | 11 3/4 | 11 3/4 | 13 | N/A | 11 3/4 | 11 3/4 | 13 | N/A | 11 3/4 | 11 3/4 | 13 | 19 | 13 |
| Specs |  | | | | | | | | | | | | | |
| Drawings | | | | | | | | | | | | | | |
| Product # | SIBASR-24 | SIBASR-30 | SIBASR-36 | SIBASR-42 | SIBASR-48 |
| Description | 24"single tier speed rail for bar sink | 30"single tier speed rail for bar sink | 36"single tier speed rail for bar sink | 42"single tier speed rail for bar sink | 48"single tier speed rail for bar sink |
| Specs | | | | | |
| Drawings | | | | | |
| Product # | SIBASR2-24 | SIBASR2-30 | SIBASR2-36 | SIBASR2-42 | SIBASR2-48 |
| Description | 24"double tier speed rail for bar sink | 30"double tier speed rail for bar sink | 36"double tier speed rail for bar sink | 42"double tier speed rail for bar sink | 48"double tier speed rail for bar sink |
| Specs | | | | | |
| Drawings | | | | | |
