Manual Griddles

  • Available in 12", 24", 36", 48" & 60" widths
  • Independent mechanical snap-action manual controls
  • 1" griddle plate with continuous heat output
  • Thermostat range 200°F to 450°F (93°C to 232°C)
  • Cool-to-the-touche front S/S edge
  • All stainless steel cabinet
  • Back and side splash guards are fulling welded to the griddle plate
  • Operator-friendly controls
  • Robust construction, all stainless-steel cabinets
  • Adjustable stainless steel non-skid feet
  • Easy to remove 4 1/2" quart grease drawer with weep hole
  • Shipped standard, Natural gas or LP conversion kit included
  • Gas prssure regulator supplied with the unit
  • Gas hose kit available for purchase: SIF-HG-4D-48SEL
ETL Listed
ETL Sanitation Listed

Product Specifications
Product# HGM12-NHGM12-PHGM24-NHGM24-PHGM36-NHGM36-PHGM48-NHGM48-PHGM60-NHGM60-P
Width 12.0”12.0”24.0”24.0”36.0”36.0”48.0”48.0”60.0”60.0”
Depth 28.7”28.7”28.7”28.7”28.7”28.7”28.7”28.7”28.7”28.7”
Height 15.4”15.4”15.4”15.4”15.4”15.4”15.4”15.4”15.4”15.4”
Weight 99.0 lbs99.0 lbs150.9 lbs150.9 lbs220.0 lbs220.0 lbs283.8 lbs283.8 lbs338.8 lbs338.8 lbs
Gas Type Natural GasLiquid PropaneNatural GasLiquid PropaneNatural GasLiquid PropaneNatural GasLiquid PropaneNatural GasLiquid Propane
Griddle Width 12”12”24”24”36”36”48”48”60”60”
# of Control 1122334455
# of Burners 1122334455
BTU per Burner 30000300003000030000300003000030000300003000030000
Total BTU Output 300003000060000600009000090000120000120000150000150000
Opertating Gas Pressure 4.0” W.C10.0” W.C4.0” W.C10.0” W.C4.0” W.C10.0” W.C4.0” W.C10.0” W.C4.0” W.C10.0” W.C
Specs pdfpdfpdfpdfpdfpdfpdfpdfpdfpdf
Drawings pdfpdfpdfpdfpdfpdfpdfpdfpdfpdf
