Electric Range
Model : HRG-ELC 24 SERIES
- Electro-mechanical heavy-duty oven thermostat (150°F/66°C to 550°F/288°C)
- Tubular heating elements, infinite switch controlled
- Full-width pull-out stainless steel crumb tray
- Oven interior side guides & bottom porcelain-coated
- Stainless steel front and back riser and lift-off high shelf
- Stainless Steel exterior with 10” (254mm) high stainless-steel backsplash
- Cool-touch oven door handle
- Removeable, 3-position, rack guides w/1 oven rack
- 6” (152 mm) stainless steel legs are adjustable
- Also available in a 36” width version
- Requires 208 or 240 volt, 1 or 3-phase power supply
ETL Listed
ETL Sanitation Listed
NSF Certified
Product Specifications
| Product# | HRG24-12GM-2B-ELC | HRG24-24GM-ELC | HRG24-4B-ELC |
| Width | 24.0" | 24.0" | 24.0" |
| Depth | 30.8" | 30.8" | 30.8" |
| Height | 59.1" | 59.1" | 59.1" |
| Weight(lbs) | 305.8 | 314.6 | 226.6 |
| # of Ovens | 1 | 1 | 1 |
| Oven Watts | 5 kW | 5 kW | 5 kW |
| Temp Range °C | 66°C to 288°C | 66°C to 288°C | 66°C to 288°C |
| Temp Range °F | 150°F to 550°F | 150°F to 550°F | 150°F to 550°F |
| # of Racks | 1 | 1 | 1 |
| Broiler Watts | 1.25kW | 1.25kW | 1.25kW |
| Griddle Width | 12” | 24” | - |
| Griddle Watts / 12” | 4 kW | 4 kW | - |
| # of Burner | 2 | - | 4 |
| Watts per Burner | 2 kW | - | 2 kW |
| Voltage | 208V/3P | 208V/3P | 208V/3P |
| Plug | Hard Wired | Hard Wired | Hard Wired |
| Spcs |  | | |
| Drawings | | | |
- 1 year parts and labour
- For full warranty details https://www.efifoodequip.com/page/warranty_info
- Specifications subject to change without notice.
