Enclosed Bases With Or Without Backsplash
Keep the work area cleaner and free of clutter. Available with or without a 4” backsplash
Enclosed Bases Models: TEC3048, TEC3060, TEC3072, TEC3084, TEC3096
Enclosed Bases With Backsplash Models: TECB3048, TECB3060, TECB3072, TECB3084, TECB3096
- Keep the work area cleaner and free of clutter
- Available with or without a 4” backsplash
- Sliding doors for access to under table storage
- Heavy duty, 18 gauge, Type 430 stainless steel top provides long life
- Top is TIG welded
- Entire top surface is machine polished to a satin finish
- Reinforced to exceed industry standards
- Galvanized hat channels are secured to top by structural adhesive and weld studs
- Gussets welded to support hat sections
- Hemmed edges provide strength and safety
- Simple assembly
- Shipped unassembled for reduced cost and space
- Galvanized legs and undershelf for durability and economy
- Sides and doors made with 18 gauge Type 430 stainless steel
- Die cast reinforced leg sockets for stability
- Legs are 1 5/8” diameter
- Adjustable ABS bullet feet to accommodate uneven flooring
- 84“ and above have 6 legs
| Product# | Width | Shipping Dimensions W | Weight (lbs) | Specs | Drawings |
|---|---|---|---|---|---|
| TEC3048 | 48" | 51"x33"x8" | 125 |  |
|
| TEC3060 | 60" | 63"x33"x8" | 147 | |
|
| TEC3072 | 72" | 75"x33"x8" | 169 | |
|
| TEC3084 | 84" | 87"x33"x8" | 198 | |
|
| TEC3096 | 96" | 99"x33"x8" | 218 | |
|
| Product # | Width | Shipping Dimensions W | Weight (lbs) | Specs | Drawings |
|---|---|---|---|---|---|
| TECB3048 | 48" | 51"x33"x12" | 131 | |
|
| TECB3060 | 60" | 63"x33"x12" | 153 | |
|
| TECB3072 | 72" | 75"x33"x12" | 175 | |
|
| TECB3084 | 84" | 87"x33"x12" | 206 | |
|
| TECB3096 | 96" | 99"x33"x12" | 228 | |
|
